Breath First Traversal

It is an algorithm that lets you explore a tree of a graph. This algorithm explores all the nodes at the present depth level before moving on to nodes at the next depth level. Breath First Traversal uses queues to track nodes that need to be visited next.

Implementation

Steps

• Start at the root or arbitrary node
• Visit the node and add all neighbours to the queue
• Dequeue the node and enqueue neighbours
• Repeat until the queue is empty

Code Example

function breadthFirstTraversalGraph(graph: Record<string, string[]>, start: string): void {
  const queue = [start]; // Queue to track the nodes to visit
  const visited = new Set<string>(); // Set to track visited nodes

  while (queue.length > 0) {
    const node = queue.shift()!; // Dequeue the first node from the queue

    if (!visited.has(node)) {
      console.log(node); // Visit the node
      visited.add(node); // Mark the node as visited

      // Enqueue all unvisited neighbors
      for (const neighbor of graph[node]) {
        if (!visited.has(neighbor)) {
          queue.push(neighbor);
        }
      }
    }
  }
}

// Example graph
const graph = {
  A: ['B', 'C'],
  B: ['A', 'D'],
  C: ['A', 'D'],
  D: ['B', 'C'],
};

// Perform BFS starting from node 'A'
breadthFirstTraversalGraph(graph, 'A');
// Output: A, B, C, D
